13 thoughts on “All Recordings Are DSD…NOT!

  • May 23, 2015 at 5:47 pm
    Permalink

    Last month Peter Aczel of the Audio Critic published his “What I have learned after six decades in audio (call it my journalistic legacy)”. Although I may not agree with what he wrote 100%, there’s more truth here than what I read in 95% of what is written in all the hi end mags and websites. Here’s a bit of his thoughts on digital audio, read the rest here.
    http://www.theaudiocritic.com/audio-legacy-2/

    “We should all be grateful to the founding fathers of CD at Sony and Philips for their fight some 35 years ago on behalf of 16-bit, instead of 14-bit, word depth on CDs and 44.1 kHz sampling rate. Losing that fight would have retarded digital media by several decades. As it turned out, the 16-bit/44.1-kHz standard has stood the test of time; after all these years it still sounds subjectively equal to today’s HD techniques—if executed with the utmost precision. I am not saying that 24-bit/192-kHz technology is not a good thing, since it provides considerably more options, flexibility, and ease; I am saying that a SNR of 98.08 dB and a frequency response up to 22.05 kHz, if both are actually achieved, will be audibly equal to 146.24 dB and 96 kHz, which in the real world are never achieved, in any case. The same goes for 1-bit/2.8224 MHz DSD. If your ear is so sensitive, so fine, that you can hear the difference, go ahead and prove it with an ABX test, don’t just say it.”

    Reply
    • May 24, 2015 at 12:43 pm
      Permalink

      Thanks Sal, I read the article and have a great deal of respect for Peter. A lot of what he states is interesting and has merit but he misses the mark on a number of important issues as well. Even the segment you quoted above contains some factual errors and and bad information. CDs don’t have a dynamic range of 98.08 unless you don’t count the dithering that is present all of the time…the number is actually 94 dB. Same problem with the 24-bit number. His evaluation of high-resolution audio equates high-res PCM with DSD 64…which are not remotely similar. Go figure.

      Reply
      • May 24, 2015 at 5:44 pm
        Permalink

        I’d give Pete a break on his digital math, this stuff requires at least a masters in engineering to understand. Even you called on John Siau to pen the response to CA.
        I think the point Peter (and myself) are trying to make here is that a Red Book CD “if executed with the utmost precision” would be very hard to differentiate from a HD recording also done with the same utmost precision. Not impossible, but very difficult, requiring trained ears and excellent equipment.
        Also what he has done is call out for ABX trial of the different processes and including a DSD file would make for a very interesting outcome.
        I already proven to myself with your files that I can’t hear the deference. LOL

        Reply
        • May 25, 2015 at 9:32 am
          Permalink

          I agree with your assessment. CD, when done with great care, can produce absolutely stunning results. When a good CD is compared to a good HD-Audio recording, they are very difficult to differentiate.

          Reply
  • May 23, 2015 at 8:18 pm
    Permalink

    Thank you for this post, most enlightening.

    Reply
  • May 23, 2015 at 8:36 pm
    Permalink

    Mark,

    While I’m sure that John Siau’s response is correct, it leaves unsaid the most important rebuttal point – the assertion that converting analog to PCM involves going through DSD first. If that’s untrue, the rest of the DSD faithful’s argument fails from the outset, as it’s based on a fallacy.

    I don’t work in the field, so I don’t know whether it’s true or not, but I seriously doubt it could be true, and that going from analog through DSD to get to PCM is ever done except in the rare case of making a PCM version of something archived in DSD.

    As to the bit yesterday about “multi-channel mono,” that would be true if only one mike was used per instrument; using two enables positioning a stereo image of each instrument in the overall mix. Maybe you should use five for locating it in the oveall surround mixes!

    Reply
    • May 24, 2015 at 12:51 pm
      Permalink

      Phil, the central issue that John makes very clear is that “converting analog to PCM” does not involve a path through DSD encoding, unless you make the error of equating multibit SDM (sigma delta modulation) with 1-bit DSD. It is extremely rare to find a production that was created in DSD and them converted to PCM. I believe that Blue Coast does it and maybe a couple of others but it makes no sense. Conversions the other way…from PCM or DXD…to DSD does happen. It’s also a conversion that lowers the fidelity of the original recording but some see greater value in DSD and thus do these conversions and charge more for them.

      The level of misinformation regarding DSD is amazing!

      Reply
  • May 24, 2015 at 3:00 am
    Permalink

    John’s response is also a bit of a cop-out. The poster on CA was using “DSD” as a catchall to refer to SDM as “DSD” is a more well known acronym. So the poster on CA is correct that nearly all modern DACs convert PCM to SDM (in this case it could be called multi-bit DSD in the vernacular). This is clear if you follow the whole discussion and know the previous posts made by this poster.

    John’s response is a literalist one ( as he is reacting only to your quote), and interprets the post as seeming to say that modern DACs convert all PCM to 1 bit DSD. But that isn’t what the post was saying.

    Almost all modern DACs DO convert PCM to SDM, so the point of the CA poster is well taken (convert DSD here to SDM or “multi-bit DSD” as it is sometimes called for convenience):

    That’s what happens with a ‘PCM’ recording. Everything you read where people complain about the deficiencies of DSD describes everything you have ever listened to through a DAC, the sole rare exception being if you listen only to material recorded before the late-80s/early-90s takeover of sigma-delta ADCs and do so only through an R2R DAC. That’s it. So when John Siau and Mark Waldrep talk about the sound of DSD, they are describing an unavoidable stage of every 24/96 recording Mark Waldrep ever made and everything John ever heard from his sigma-delta DACs. If they say they prefer the ‘sound of PCM,’ then what they must prefer is what is being lost during the lossy conversions to and from DSD format.”/

    So the poster on CA, taken in context, is correct.

    Reply
    • May 24, 2015 at 3:04 am
      Permalink

      Sorry, dyslexia strikes. Meant DSM (Delta Sigma Modulation), not SDM.

      Reply
    • May 24, 2015 at 12:56 pm
      Permalink

      Sorry Danny, I did read a great deal of the poster’s comments. Equating DSD (which is universally marketed a “1-bit” SDM) is not the same a multibit SDM. There is not such thing as multibit DSD. When you move past 1-bit, it becomes PCM and dithering becomes a possible. The thought that John’s equipment and my recordings have passed through a DSD (1-bit SDM) stage is wrong.

      Reply
    • May 14, 2016 at 8:05 am
      Permalink

      The real path inside the modern DAC’s:
      PCM stream –> INTERPOLATION FILTER (decimation) –> one or multibit DSM conversion –> DSD stream –> SC DAC –> ANALOG signal

      If the DAC DSD capable the path is sorter: DSD stream –> SC DAC –> ANALOG signal
      The DSM conversion can be one or multi bit, the multi bit DS modulator give better quality DSD stream on the output.
      The AD conversion is the same in the reverse way. The DSD –> PCM or PCM –> DSD conversion is always lossy.

      Reply
      • January 4, 2018 at 2:44 pm
        Permalink

        thanks for clarifying , but as someone pointed out, are all modern recordings done in DSD (1 bit stream) ? I know Sony did/maybe still does on their redbook CDs in the 90s, but they don’t even have SACDs (at least not common)
        I thought they are all made driectly as 24 bit recording (at least as stated on the CDs), in other words,
        PCM straight away without all those conversion they talk about.
        So are all these so called 24 bit recordings are really fake ones but are 1 bit that turn to 24 bits and then you can down load them as 24 bit Hi RES FLAC or they may have SACD versions but that is also really from DSD to PCM and back to DSD process ???! I am confused, the more I read!

        Reply
  • May 25, 2015 at 6:30 pm
    Permalink

    Brilliant, educational article. Thank you.

    Reply
